8720SM Motor Specifications and Performance Curves
Regenerative Power Supply Specifications
Because of the larger current requirements for motors from 45 to 75
kW a master 37 kW regenerative power supply (RPS) and a slave 37
kW RPS are required. Each master or slave RPS requires its own line
reactor, harmonic filter and varister. The master and slave RPS units
are designed to share the current loads equally so incoming AC fuses
and wiring should be sized accordingly.
Specifications for 8720MC-RPS Master and Slave(s) Regenerative Power Supplies with 750V dc Drives and 8720SM AC Motors
8720MC-RPS065 Regen. P.S.
Units
Power Supply Specifications
Motor catalog number
8720SM-
045S5NA
055S5PA
063S5QA
075S6SA
093S6TA
Drive amplifier catalog number
8720MC-
D097
D120
D120
D149
D180
Regenerative Power Supply catalog
number
8720MC-
RPS065
BM and BS
RPS065
BM and BS
RPS065
BM and BS
RPS065
BM and BS
RPS190
BM
AC input voltage AC+10/-15%
RMS Volts
380 to 460
380 to 460
380 to 460
380 to 460
380 to 460
Input frequency
Hz ±3%
50/60
50/60
50/60
50/60
50/60
Input power factor
0.98
0.98
0.98
0.98
0.98
Required input kVA
kVA
56.5
72.4
83.6
99.5
122.5
Required input current
Amps RMS
71
91
105
125
154
Required input 1 min current
Amps RMS
106.5
136.5
157.5
187.5
231
Required output kVA
kVA
49.3
60.6
69.4
83.2
101.9
Required output current
Amps DC
65.7
80.8
92.5
110.9
135.9
Required max current (1 min)
Amps DC
98
121
139
166
204
Design Bus voltage
Volts DC
750
750
750
750
750
Rated input kVA
kVA
100
100
100
100
150
Rated input current
Amps RMS
130
130
130
130
195
Rated input 1 min current
Amps RMS
196
196
196
196
292
Rated output kVA
kVA
90
90
90
90
135
Rated output current
Amps DC
128
128
128
128
192
Rated max output current (1 min)
Amps DC
192
192
192
192
288
Operating Temperature (open)
deg C
0 to 50
0 to 50
0 to 50
0 to 50
0 to 50
Operating Temperature (Nema1)
deg C
0 to 40
0 to 40
0 to 40
0 to 40
0 to 40
Storage temperature
deg C
-40 to 85
-40 to 85
-40 to 85
-40 to 85
-40 to 85
Ambient humidity
%
5 to 95%
5 to 95%
5 to 95%
5 to 95%
5 to 95%
Altitude
m (ft)
1000 (3300)
1000 (3300)
1000 (3300)
1000 (3300)
1000 (3300)
Shock
G peak for 11
ms
15
15
15
15
15
Vibration
mm (in)
Displacement
at 1g
0.152 (.0006)
0.152 (.0006)
0.152 (.0006)
0.152 (.0006)
0.152 (.0006)
Weight
kg (lbs)
38.6 (85)
108.9 (240)
108.9 (240)
108.9 (240)
108.9 (240)
