Publication 8720MC-IN002A-EN-P — December 2002
Programming Parameters C-71
Name: Motor_Max_Volts Data Type: unsigned Integer R/W
Parameter No.
783
File:
Motor/Drive/
Fdbk
Group:
Motor Data Description: This parameter defines the maximum DC bus voltage required in the constant power region.
Default:
Motor
Specific Length
2 bytes Minimum/Maximum
Min.
≥ 0
Max. ≤ +6553.5
Scaling Resolution
.1 Units
volts
Name: Mtr_Rated_Volts Data Type: Unsigned Integer R/W
Parameter No.
784
File:
Motor/Drive
Group:
Motor Data Description: This parameter defines the nominal DC bus voltage required to achieve base speed and rated
torque.
Default:
Motor
Specific Length
2 bytes Minimum/Maximum
Min.
≥ 0
Max.
≤ +6553.5
Scaling Resolution
.1 Units
volts
Name: Rated_Torque Data Type: Unsigned Integer R/W
Parameter No.
785
File:
Motor/Drive/
Fdbk
Group:
Motor Data Description: This parameter defines the continuous torque rating of the motor at base speed (8720SM) and stall
(MPL-B8xxx/-B9xxx) at 40° C
Default: Length
2 bytes Minimum/Maximum
Min.
≥ 0
Max.
≤ +6553.5
Scaling Resolution
10
-1
Units
newton-me
ters or
newtons
Name: Motor_Back_EMF Data Type: Unsigned Integer R/W
Parameter No.
786
File:
Motor/Drive/
Fdbk
Group:
Motor Data Description: This parameter defines the synchronous motor (MPL-B8xxx/-B9xxx) back emf phase to phase
constant at 25° C. This is set to zero for asynchronous motors (8720SM).
Default:
0 Length
2 bytes Minimum/Maximum
Min.
≥ 0
Max. ≤ +655.35
Scaling Resolution
10
-2
Units
volts rms
