Publication 8720MC-IN001D-EN-P — December 2002
8720SM Motor Specifications and Performance Curves D-11
8720MC Drive Amplifier Specifications
8720MC Line Reactor Specifications
8720MC Drive Amplifier Specifications for 750V dc Input 8720MC-RPS Regenerative Power Supplies and 8720SM AC Motor
Drive Amplifier Specifications Units Drive Amplifier Data for Each Power Rating
Motor catalog number 8720SM- 045S5NA 055S5PA 063S5QA 075S6SA 093S6TA
Rated Continuous motor current at
base speed
Amps (RMS cont.) 93 116 117.5 137 176
Drive amplifier catalog number 8720MC- D097 D120 D120 D149 D180
DC input current @ 750V dc Amps 65.7 80.9 92.6 111.1 135.3
Max continuous output power kW (hp) 45 (60.3) 63 (84.4) 63 (84.4) 75 (100.5) 93 (125)
Max continuous output current Amps 97 120 120 149 180
DC Bus Capacitance µF 9000 9000 9000 9000 12000
Drive amplifier frame D D D D D
Weight kg (lbs) 108.9 (240) 108.9 (240) 108.9 (240) 108.9 (240) 108.9 (240)
8720MC Line Reactor Specifications for 750V dc Input Drives with Multiple 8720MC-RPS Regen Power Supplies and 8720SM AC Motor
Line Reactor Specifications Units Line Reactor Data for Each Power Rating
Motor catalog number 8720SM- 045S5NA 055S5PA 063S5QA 075S6SA 093S6TA
Req. RPS continuous Input current Amps RMS 71 91 105 125 154
Drive amplifier catalog number 8720MC- D097 D120 D120 D149 D180
Line Reactor catalog number 8720MC- LR05-048B LR05-048B LR10-062B LR14-070B LR10-100B
Number of Reactor Assemblies Req quantity 2 2 2 2 2
Max cont. current Amps RMS 48 48 62 70 62
Inductance uH 800 800 1100 1200 1100
Weight kg (lbs) 21 (46.2) each 21 (46.2) each 27 (59.4) each 38 (83.8) each 27 (59.4) each
