Publication 8720MC-IN002A-EN-P — December 2002
Programming Parameters C-69
Name: Motor_Param_Rev Data Type: Integer R
Parameter No.
742
File:
Motor/Drive/
Fdbk
Group:
Motor Data Description: The 8720SM Motor parameters are subject to revision over time. Parameter 742 is used to identify
the revision number of the motor parameters
Default: Length
1 byte Minimum/Maximum
Min.
≥ 0
Max. ≤ +255
Scaling Resolution
1 Units
N/A
Name: Motor_Select Data Type: Ascii enumeration of motor catalog
numbers R/W
Parameter No.
777
File:
Motor/Drive/
Fdbk
Group:
Motor Data Description: The standard 8720SM Motors have assigned 8720SM catalog numbers. Parameter 777 provides a
list of the available standard 8720 motors. If the motor catalog number does not appear on the list “custom” must
be entered and all motor specific parameters must be entered individually. For standard MPL-B8xxx, -B9xxx, and
8720SM motors this parameter is set by the data stored in the encoder and cannot be changed unless the
feedback is disconnected and power recycled.
Default:
custom Length
2 bytes Minimum/Maximum
0 to 65535 Scaling Resolution
N/A Units
N/A
Name: Motor_Type Data Type: binary R/W
Parameter No.
778
File:
Motor/Drive/
Fdbk
Group:
Motor Data Description: The 8720MC can be used with several different types of motors. Parameter 778 identifies the type
of motor the 8720MC is connected to. The possible enumerations are:
* 000 - Rotary PM Brushless
* 001 - Rotary Induction
* 010 - Rotary Induction Dual Winding
* 011 - Linear PM Brushless
* 100 - Linear PM Brushless AC Ironless
Default:
001 Length
1 byte Minimum/Maximum
0 to 255 Scaling Resolution
N/A Units
N/A
Name: Motor_Pole_Count Data Type: unsigned Integer R/W
Parameter No.
779
File:
Motor/Drive/
Fdbk
Group:
Motor Data Description: Parameter 779 provides the drive with the number of motor poles. If the motor is a linear motor this
parameter provides the linear motor pole pitch in millimeters
Default:
4 Length
1 byte Minimum/Maximum
2/255 Scaling Resolution
N/A Units:
poles/rev
poles/mm
