Rockwell Automation Publication 7000-IN006B-EN-P - May 2013 87
Commissioning the Drive Chapter 5
View
Use the View feature to observe the samples recorded during the last diagnostic
trend.
Configuring Trending
The trending setup is best illustrated through an example:
Trend Read-Only Parameters—Trend Data:
Trigger Defines whether you want a continuous or a single-shot
trigger. Pressing this key will place an S or a C in front of
the trigger parameter. You will almost always want a
Single-Shot (S) trigger.
S = Single shot>>the trigger occurs once and stops,
trigger must be manually re-armed
C = Continuous capture>>auto re-arm enabled to collect
new trends until stopped by viewing contents of captured
data
Cond Defines the Condition that will cause the trigger. The
possible options are:
= (Equal to)
N= (Not Equal to)
> (Greater than)
< (Less than)
+ (Boolean OR)
N+ (Boolean NOR)
& (Boolean AND)
N& (Boolean NAND)
Data Defines the trigger value with respect to the Read-Only
Parameter in Trace 1.
16) Line Current pu: 122
15) Alpha Rectifier: 327
14) Idc Fbk Sampled: 329
13) Idc Reference: 321
12) Line Voltage pu: 135
11) Motor Current pu: 555
10) Motor Voltage pu: 554
9) StatFrqVoltModel: 485
8) Flux Feedback: 306
7) Torque Reference: 291
6) Speed Feedback: 289
5) Speed Reference: 278
4) RecControl Flag2: 160
