Sgct power supplies (igdps) – Rockwell Automation 7000 PowerFlex Medium Voltage (B Frame) Commissioning - ForGe (PanelView 550) User Manual
Page 76
72
Rockwell Automation Publication 7000-IN006B-EN-P - May 2013
Chapter 5 Commissioning the Drive
SGCT Power Supplies (IGDPS)
Note: Refer to
below for location of IGDPS.
Figure 45 - Converter Cabinet Components (2400V)
Note: For variations in drive cabinetry (such as the heat pipe B Frame or Marine
liquid-cooled drives) please refer to the appropriate Installation Manual for that
drive.)
Ground bus
Temperature
Feedback
Board (Inverter)
Isolated Gate
Driver Power
Supplies
Temperature
Feedback
Board (Rectifier)
Rectifier
Modules
Inverter Modules
Differential
Pressure
Sensor
