6600 v with afe rectifier – Rockwell Automation 7000 PowerFlex Medium Voltage (B Frame) Commissioning - ForGe (PanelView 550) User Manual
Page 18
14
Rockwell Automation Publication 7000-IN006B-EN-P - May 2013
Chapter 2 PowerFlex 7000 Overview
6600 V with AFE Rectifier
Figure 6 - 6600 Volt – AFE Rectifier, Configuration #1 – Direct-to-Drive
Figure 7 - 6600 Volt – AFE Rectifier, Configuration #2 – Separate Isolation Transformer
SGCTs
LINE CONVERTER
L+
M+
SGCTs
MACHINE CONVERTER
U (T1)
V (T2)
W (T3)
L-
M-
LR
OMMON MODE CHOKE
C
SGCTs
LINE CONVERTER
DC LINK
L+
M+
SGCTs
MACHINE CONVERTER
U (T1)
V (T2)
W (T3)
L-
M-
REMOTE
ISTX
2U (X1)
2V (X2)
2W (X3)
1U
1V
1W
