Table 9 - PowerFlex Speed Regulation

Notes:

Speed regulation is based on a percentage of motor synchronous speed.
Tachometer to be mounted on the AC machine
Operational 15 V DC Power Supply mounted in drive to power the

tachometer as a standard option with the tachometer feed back card.

Customer is responsible for providing and mounting of tachometer
Sleeve bearing motors require the tachometer to have an axial movement

tolerance.

Recommended tachometers are shaft mounting type.
Magneto resistive models are more adaptable to harsh environments.
When installing, the tachometer body and electronics must be isolated

from ground (options available from the tachometer manufacturer to
accomplish this).

There are usually limits on tachometer cable lengths. Ensure the maximum

length is suitable for the application.

PowerFlex 7000 Drive
Performance (Torque
Capabilities)

The PowerFlex 7000 drives have been tested on a dynamometer to verify
performance under locked rotor, accelerating, and low speed-high torque
conditions. Table A-5 below shows the PowerFlex 7000 drive torque capabilities
as a percent of motor rated torque, independent of the drive’s momentary
overload conditions.

Tachometer

Frequency Output

<6 Hz

6-15 Hz

>15 Hz

Without Tachometer

Not applicable

0.1%

0.1%

With Tachometer

0.02%

0.01%

0.01%

Recommended Tach PPR

Motor RPM

Tach ppr

3600

600

3000

600

1800

1024

1500

1024

1200

2048

1000

2048

900

2048

720

2048

600

2048
