Page 17
Rockwell Automation Publication 7000-IN006B-EN-P - May 2013
13
PowerFlex 7000 Overview Chapter 2
3300/4160V with AFE Rectifier
Figure 4 - 3300/4160 Volt – AFE Rectifier, Configuration #1 – Direct-to-Drive
Figure 5 - 3300/4160 Volt – AFE Rectifier, Configuration #2 – Separate Isolation Transformer
SGCTs
LINE CONVERTER
L+
M+
SGCTs
MACHINE CONVERTER
U (T1)
V (T2)
W (T3)
L-
M-
LR
OMMON MODE CHOKE
C
SGCTs
LINE CONVERTER
DC LINK
L+
M+
SGCTs
MACHINE CONVERTER
U (T1)
V (T2)
W (T3)
L-
M-
REMOTE
ISTX
2U (X1)
2V (X2)
2W (X3)
1U
1V
1W
