Chapter 1 Important User Information
If you have multiple drive types or power ranges, ensure you have the correct
documentation for each specific PowerFlex 7000 product:
• “A” Frame for lower power air-cooled configurations (up to approximately
1250 hp/933 kW)
• “B” Frame for higher-power, air-cooled configurations (standard or heat
pipe models)
• “C” Frame for all liquid-cooled configurations
Manual Conventions This manual uses a variety of symbols to indicate specific types of information.
General Precautions
Warnings indicate where people may be hurt if users do
not follow procedures properly.
Cautions indicate where machinery damage or economic
loss may occur if users do not follow procedures properly.
Both of the above symbols could indicate:
• A possible trouble spot
• Tell what causes the trouble spot
• Give the result of an improper action
• Tell the reader how to avoid trouble
This symbol indicates a potential electrical shock hazard
on a component or printed circuit board.
W A R N I N G W A R N I N G
A T T E N T I O N A T T E N T I O N
S H O C K H A Z A R D S H O C K H A Z A R D
ATTENTION: This drive contains ESD (Electrostatic Discharge) sensitive parts
and assemblies. Static control precautions are required when installing, testing,
servicing or repairing this assembly. Component damage may result if ESD
control procedures are not followed. If you are not familiar with static control
procedures, reference Allen-Bradley publication 8000-4.5.2, “Guarding Against
Electrostatic Damage” or any other applicable ESD protection handbook.
