Rockwell Automation Publication 7000-IN006B-EN-P - May 2013

81

Commissioning the Drive Chapter 5

Status Indicators

Drive status is often feedback to a plant’s process control either digitally through
the PLC input/output feature (refer to the relevant PowerFlex 7000 Installation
Guides or user Manuals for PLC programming details) or through relay logic.
The following relays are provided with the drive as standard:

It is necessary to activate each status indicator used by the customer to ensure that
they have connected their control to the drive correctly. This can be achieved by
changing the drive status (ready, faulted, warning etc.).

Analog I/O

It is possible to configure all of the drive’s analog inputs and outputs without
running the motor. The following information describes how to set up the
following drive features:

• Analog Inputs

– Analog Reference Command Input Scaling (Local, Remote)
– Minimum Setting
– Maximum Setting
– Digital Reference Command Input Scaling (Digital)

• Analog Outputs

All of the Analog I/O connections occur on the ACB.

Analog Inputs

• Analog Command Input Scaling

– Prior to commencing the reference command input scaling it is

necessary to ensure that the reference command input selection has
been configured as desired. This requires setting Reference Select [P7]
to the appropriate input source.

Relay Name

Relay Designation

Run Contact

RUN

Fault Contact

FLT

Warning Contact

WRN

Ready Contact

RDY
