Rockwell Automation Publication 7000-IN006B-EN-P - May 2013 119
Appendix
A
General Reference
Torque Requirements for
Threaded Fasteners Unless otherwise specified, use the following values of torque in maintaining the
equipment.
Diameter Pitch Material Torque (N-m) Torque (lb.-ft.)
M2.5 0.45 Steel 0.43 0.32
M4 0.70 Steel 1.8 1.3
M5 0.80 Steel 3.4 2.5
M6 1.00 Steel 6.0 4.4
M8 1.25 Steel 14 11
M10 1.50 Steel 29 21
M12 1.75 Steel 50 37
M14 2.00 Steel 81 60
1/4” 20 Steel S.A.E. 5 12 9.0
3/8” 16 Steel S.A.E. 2l 27 20
