Commissioning Preparations Chapter 4
• The PowerFlex 7000 “B” Frame Commissioning Guide: This is a Rockwell
Automation-internal document for commissioning engineers conducting
commissioning procedures. Customers can request copies of the manual
from their local Rockwell Automation Office.
• The PowerFlex 7000 Medium Voltage AC Drive Parameters (Technical
Data publication 7000-TD001_-EN-P): Use this document for parameter
details and programming during commissioning or troubleshooting. Refer
to 7000-TD002_-EN-P for the latest firmware revision.
• The PowerFlex 7000 “B” Frame User Manual: Use this document for
general information regarding the usage and programming of the operator
interface after installation (before or after commissioning.)
• Additional Manuals: The electrical schematics that ship with the drive
should list any additional manual necessary for configuring the drive line-
up. The schematic titled “General Notes” identifies all required Rockwell
Automation publications by publication number.
Important Note for the
Commissioning Engineer
The commissioning engineer should review this commissioning package and
follow the defined steps to commission PF7000 drive(s). It is the responsibility of
the commissioning engineer to complete all datasheets included in this package
and collect any other relevant information that may not have been included in the
package. Important guidelines for capturing waveforms are also included in the
package for quick reference. These must be reviewed and followed properly by
the commissioning engineer. Anything that is not clear, please contact MV Tech
Support for assistance:
Phone: 519-740-4790
Option 1 for technical and option 4 for commissioning questions
[email protected] or
[email protected]
After successful commissioning of the drive, the commissioning engineer is
required to return the completed commissioning package along with his field
service reports to the project manager within one week after completion of job. If
job is not completed and some data collected it must be sent to project manager
within one week after leaving the site. The items listed below MUST be included
when submitting the commissioning package.
1. All checklists and tables in this document (commissioning checklist,
customer data, motor data, daily service summary, etc.)
2. Harmonics waveforms must be captured on AFE drives under drive-not-
running and full-load conditions.
IMPORTANT
Ensure you also have the latest technical and release notes for the relevent
drive firmware before proceeding with commissioning. Check the most recent
version of the Commissioning Guide for a list of updated Tech Notes.
