HĆ1
Appendix H
Quickstart Guide
WARNING
ONLY QUALIFIED PERSONNEL FAMILIAR WITH THE CONSTRUCTION AND
OPERATION OF THE CONTROLLED EQUIPMENT SHOULD INSTALL, ADJUST,
OPERATE, AND/OR SERVICE THIS EQUIPMENT. READ AND UNDERSTAND THIS
MANUAL AND OTHER MANUALS APPLICABLE TO YOUR INSTALLATION IN
THEIR ENTIRETY. FAILURE TO OBSERVE THIS PRECAUTION COULD RESULT IN
BODILY INJURY OR DAMAGE TO EQUIPMENT.
This appendix is intended for individuals who want to start using the AutoMax
Programming Executive as quickly as possible. It will be particularly useful for
those who are familiar with the Windows software and with previous versions of
the Programming Executive. Familiarity with basic concepts in the instruction
manual is assumed. This appendix presents the typical sequence of steps
followed when using the Programming Executive, but includes little of the detail
or explanatory material found in the instruction manual. This appendix also does
not describe any online functions, e.g., monitoring.
Note that this appendix does not describe how to import application tasks
created with earlier version AutoMax or DCS 5000 Programming Executives.
Help screens are available for most commands. Use the F1 key or click Help to
access help for any screen where F1 is displayed.
Installing Windows and the AutoMax Programming
Executive
1. If you have not already done so, install Windows 95 software according to the
directions in the Windows instruction manual.
2. If you have not already done so, install a mouse.
3. Install the Programming Executive using the instructions found in the
Installation manual, J2Ć3103. Instruction for installing the
separatelyĆpurchased DPS software options can be found in the same
manual.
4. Start the AutoMax Programming Executive software. The first screen
displayed after the name and copyright information is the System
Configurator, which can be thought of as the main menu," since all other
options are chosen from this screen. Choose the Setup menu and then select
one of the following commands.
Select AutoMax to run the AutoMax configuration procedure. This will allow
you to make changes to the AutoMax Executive configuration (see
section 5.5.2).
Select Communication to make changes to the communication port and
baud rate used for online communication (see section 5.5.3).
Select Printer to set the parameters for printer output (see section 5.5.4).
