12Ć6
ON LINE Direct via Serial AUTOMAX C: \SYSTEM\RACK
EscăExit
Connect Network
Slot No. 07
Increment Decrement Enter Terminate Entry
07 08
Figure 12.2 Ć Online Connect Network Menu (Select Network)
If you are using serial communication, you must select the slot in the
local rack that contains the Network Communications module (M/N
57C404A and later) which is on the network that contains the rack
you want to communicate with. Use the up and down arrows to scroll
through the available slots, which are displayed on the screen, or
type the number of the slot. When you have selected a slot, enter
. The Executive software will display the screen shown in
figure 12.3.
