13Ć1

13.0 ONLINE MENU: INFO/LOG

Entering I" for Info/Log from the Online menu allows you to display

information about the system software on any AutoMax Processor,

PC3000 Processor, or UDC module in the rack or to view the status

and error log, if any, for a selected task.

13.1

Info/Log Processor and UDC Information

Display

If you select Info/Log without having selected a task by using the

Enter key or , AutoMax will assume you want to display

information about an AutoMax Processor and the Common Memory

module (M/N 57C413B or 57C423), a PC3000 Processor, or a UDC

module. You will be prompted for the slot number of the module of

interest.

AutoMax Processor or PC3000 Processor

Figure 13.1 shows a sample display for an AutoMax Processor in slot

1 with no Common Memory module. Figure 13.2 shows a sample

internal PC3000 Processor.

ON LINE Direct via Serial

C: \LIB\SYS\RACK

EscăExit

Info/Log

Control Processor Information for Slot 1

CPU Error Code:

N/A

Network Error Code: N/A

AB Remote I/O Error Code: N/A

Network Drop:

N/A

Software ID:

422526Ć001C STD

Clock Tick (micro sec):

5500

CPU Utilization:

34%

Memory

Memory

Largest

Used

Free

Free Block

Battery

PROCESSOR 2924

151280

151280

Replace

COMMON

N/A

N/A

N/A

N/A

Figure 13.1 Ć Info/Log Processor Information Display
