EĆ1

Appendix E

Database Definitions

The relevant fields in each of the AutoMax Executive databases are described

here. Any fields not identified here are reserved for future use and should be left

unused. All of the following database files are intended as read only.

Database: $SYSTEM.DBF
FIELD

TYPE

DESCRIPTION

ID

CHARACTER

The name of the system

DESC

CHARACTER

The description of this system

ENGINEER

CHARACTER

The user responsible for this system

CUSTOMER

CHARACTER

The end user of this system

SYSTEM_VER CHARACTER

1 for V3.3 and later, otherwise 0.

Database: $SECT.DBF
FIELD

TYPE

DESCRIPTION

ID

CHARACTER

The name of the section

DESC

CHARACTER

The description of this section

ENGINEER

CHARACTER

The user responsible for this section

Database: $RACK.DBF
FIELD

TYPE

DESCRIPTION

ID

CHARACTER

The name of the rack

SECT_ID

CHARACTER

The name of the section containing

this rack

RACK_PART

NUMERIC

The rack part code from the rack

permanent table

LOCATION

CHARACTER

The physical location of this rack

DESC

CHARACTER

The description of this rack

ENGINEER

CHARACTER

The user responsible for this rack

Database: $IORACK.DBF
FIELD

TYPE

DESCRIPTION

MAST_SLOT

NUMERIC

Slot in the master rack which contains the

remote I/O card to which this rack is

connected (00Ć15)

REM_DROP

NUMERIC

This rack's drop on the remote I/O

network (1Ć7)

PORT

NUMERIC

This rack's port on remote head, if

applicable (0Ć3)
