18Ć19

18.4

Monitoring and Editing PC Tasks

The Monitor PC Program command is used to access the AutoMax

Ladder Editor which is used to monitor Ladder programs. This

command appears under the System Configurator Online menu and

the Task Manager Online menu. You cannot access the Ladder Editor

while online. If you attempt to access the AutoMax Ladder Editor from

the Online Task Manager by selecting PC from the Monitor menu

screen, you will receive the following message: Monitor PC Task via

the System Configurator or Task Manager." You must exit the Online

Task Manager and access the AutoMax Ladder Editor by using the

Monitor PC Program command. Refer to J2Ć3093 for information on

using the AutoMax Ladder Editor to monitor and edit PC tasks online.

18.5

Forcing Variables

WARNING

THE SET AND FORCE FUNCTIONS BYPASS CONTROL OF THE APPLICATION

PROCESS BY THE APPLICATION TASKS. IT IS THE RESPONSIBILITY OF THE

USER TO DETERMINE THE POTENTIAL HAZARDS INVOLVED. FAILURE TO

OBSERVE THESE PRECAUTIONS COULD RESULT IN BODILY INJURY.

WARNING

VARIABLES AND OUTPUTS WHICH ARE FORCED BEFORE AC POWER IS LOST

WILL REMAIN FORCED WHEN AC POWER IS RESTORED. SHOULD AC POWER

BE LOST WHILE VARIABLES ARE FORCED, THE USER MUST ENSURE THAT

UNEXPECTED MACHINE MOVEMENT DOES NOT OCCUR WHEN AC POWER IS

RESTORED. FAILURE TO OBSERVE THESE PRECAUTIONS COULD RESULT IN

BODILY INJURY.

From the Monitor menu shown in figure 18.1, you can select F" for

Force to force and unforce up to 64 variables at the same time. Note

that the limit of 64 forced variables applies regardless of the number

of users who have access to the rack. You can only force boolean,

single precision integer, double precision integer, and real variables.

Strings, array elements, and tunable variables cannot not be forced.

A variable that is forced cannot be altered by any application task or

the status of physical I/O. A forced variable will retain its forced value

until it is unforced or forced to a different value.
See 18.5.1 for an explanation of the screen display and 18.5.2 and

18.5.3 for instructions on forcing and unforcing variables.

18.5.1

Monitor Force Screen Display

The forcing table for a rack is divided into four pages. Each page can

list up to 16 variables, numbered 1 to 16. Pages can be switched by

using to display the next page in the table and

to display the previous page in the table. The page

numbers will scroll, meaning that, if you press from

page 4 of the table, page 1 will be displayed. If you press

from page 1 of the table, page 4 will be displayed.
