Preface

ControlGuardian User’s Guide

5-2

The parameters you select for a single action become the default selections when

you create and edit a batch file.
Figure 5.A

Single Action Function Key Descriptions

If you want to:

Press this key:

Select the master file to which the uploaded file will be compared. The master file

is selected from the master file directory.

Master File

Enter the station number to upload a program from.

Station to Upload

Use the WHO Active screen to select a station.

Ctrl

WHO Active

Select the communication hardware device. For more information, see

chapter 3.

Communications Device

Select the report configuration from the report configuration file select list. For

more information, see chapter 10.

Report Format

Select a report type:
·ladder logic
·data table
·ladder logic and data table
·partial

Report Type

Select the action type:
·Compare Only - compares a working program currently in the production

directory to a master file.

·NO-OP - skips an operation within a batch file
·Partial Upload - uploads user specified working program data as selected

from the master file of the selected PLC-5 processor.

·Partial Upload and Compare - uploads user specified working program data

as selected from the master file of the selected PLC-5 processor and

compares it to the master file.

·Retrieve & Compare - retrieves a program from disk, copies it to the

production directory, and compares it to a master file.

·Retrieve Only - retrieves a program and places it in the production directory.
·Upload & Compare - uploads the working program from the selected

processor and compares it to the master file.

·Upload Only - uploads the working program from the selected processor and

places the file in the production directory.

·Upload/B-Compare - uploads the working program from the processor and

binary compares the ladder logic to the ladder logic in the master file. Creates

an AUTO.ERR file to record matches and mismatches.

·Upload/Smart Compare - uploads the working program from the processor

and binary compares it to the master file. Generates a detailed compare report

if the ladder logic from the working file and the master file mismatch.

Action Type

Use the selected parameters to perform a single action.

Execute current operation
