Preface ControlGuardian User’s Guide
B-6
Cable Specifications
The specifications for each Allen-Bradley cable used for communications are shown
on the following pages.
For: To a: Use this cable: See page:
6160-T53
6160-T60
6160-T70
IBM PC
Compaq
1785-KE 1784-CAK B-7
1784-T47 1785-KE 1784-CXK B-8
PLC-5/10, -5/12, -5/15, -5/25
processor
programming terminal using a 1784-KT, -KT2, or -KL/B 1784-CP B-9
processor
programming terminal using a 1784-PCMK 1784-PCM5 B-15
PLC-5/11, -5/20, -5/30, -5/40,
-5/40L, -5/60, -5/60L, -5/80
processor
programming terminal using a 1784-KT, -KT2, or -KL/B) 1784-CP6 B-10
programming terminal using a 1784-KT, -KT2, or -KL/B 1784-CP6 with 1784-CP8
adapter
B-11
programming terminal using a 1784-KT, -KT2, or -KL/B 1784-CP5 with a 1784-CP7
adapter
B-12
programming terminal using a 9-pin serial cable 1784-CP10 B-13
programming terminal using a serial 25-pin cable 1784-CP11 B-14
programming terminal using a 1784-PCMK 1784-PCM5 with a
1784-CP7 adapter
B-15
programming terminal using a 1784-KTX or 1784-KTXD 1784-CP12 B-19
PLC-3, PLC-3/10 processor programming terminal using a 1784-KT, -KT2, -KL/B,
or -KTP
1784-CP3 B-16
PLC-3, PLC-3/10 processor
with 1775-S5, or -SR5
programming terminal using a 1784-KT, -KT2, or -KL/B 1784-CP B-9
PLC-3, PLC-3/10 processor
with 1770-SB
programming terminal using a serial port 1784-CAS B-17
PLC-2 processor programming terminal using a 1784-KT, -KT2, -KL/B,
or -KTP
1784-CP2 B-18
PLC-2 processor with
1770-SA, -SB
programming terminal using a serial port 1784-CAS B-17
