Configuring Communications

3-27

Configuring an A-B 1784-PCMK with a S5-104 Cable

For information on the configuration characteristics for A-B 1784-PCMK with a

S5-104 Cable, see Table 3.U.

Table 3.U

Configuration Characteristics for A-B 1784-PCMK With S5-104 Cable

If you want to:

Press this key:

Assign a unique communication device name (1-8 characters). This

field must be defined for the software to accept the configuration.

You cannot modify this field. The communication device name that

you assign appears at the top of the screen when you use WHO.

Device Name

Assign a description for a communication device (1-50 characters).

You must define this field for the software to accept

the configuration.

Enter Device Description

Select the A-B 1784-PCMK with S5-104 Cable option.

Select Interface Hardware

Assign a timeout for processor reply. Available choices are: 15, 20,

25, 30, 35, 40, 45, 50, 55 and 60 seconds. The default is

20 seconds.

Online Wait for Reply

Choose the 1784-PCMK communications board address. You can

choose from the following:
·A300H (A3)

· CB00H (CB)

·A700H (A7)

· CF00H (CF)

·AB00H (AB)

· D300H (D3)

·AF00H (AF)

· D700H (D7)

·B300H (B3)

· DB00H (DB)

·B700H (B7)

· DF00H (DF)

·BB00H (BB)

· E300H (E3)

·BF00H (BF)

· E700H (E7)

·C300H (C3)

· EB00H (EB)

·C700H (C7)

PCMK Communications

Board Addr

Define a communication rate to send information. Toggle through

300, 600, 1200, 2400, 4800, 9600 and 19200 baud rates. The

default is 19200 baud.

Baud Rate

Enter the source station address (decimal).

Ctrl

Computer Station Address
