Configuring Communications

3-33

Configuring an A-B 1784-PCMK to DH485

For information on the configuration characteristics for 1784-PCMK to DH485, see

Table 3.AA.

Table 3.AA

Configuration Characteristics for A-B 1784-PCMK to DH485

If you want to:

Press this key:

Assign a unique communication device name (1-8 characters). This

field must be defined for the software to accept the configuration.

You cannot modify this field. The communication device name that

you assign appears at the top of the screen when you use WHO.

Device Name

Assign a description for a communication device (1-50 characters).

You must define this field for the software to accept

the configuration.

Enter Device Description

Select the A-B 1784-KTX/KTXD to DH485 option.

Select Interface Hardware

Assign a timeout for processor reply. Available choices are: 15, 20,

25, 30, 35, 40, 45, 50, 55 and 60 seconds. The default is

20 seconds.

Online Wait for Reply

Choose the 1784-PCMK communications board address. You can

choose from the following:
·A300H (A3)

· CB00H (CB)

·A700H (A7)

· CF00H (CF)

·AB00H (AB)

· D300H (D3)

·AF00H (AF)

· D700H (D7)

·B300H (B3)

· DB00H (DB)

·B700H (B7)

· DF00H (DF)

·BB00H (BB)

· E300H (E3)

·BF00H (BF)

· E700H (E7)

·C300H (C3)

· EB00H (EB)

·C700H (C7)

PCMK Communications

Board Addr

Enter a programming terminal name (1- 8 characters).

Terminal Name

Enter the 1785-KA5 DH+ address (0-77 octal).

1785-KA5 Address

Enter a destination link DH+ address (decimal).

Destination Link

Enter the source station address (0-377 octal).

Ctrl

Computer Station Address
