Configuring Communications

3-21

Configuring a 1784-PCMK (DH+)

Use the 1784-PCMK (DH+) option if you want to connect a programming terminal
directly to a processor, to a local DH+ link, or for programming over a remote DH+

link. Use the 1784-PCMK option (DH+) if you are using a PCMIA programming

terminal (notebook computer).

For information on the configuration characteristics for 1784-PCMK (DH+), see

Table 3.P.

Table 3.P

Configuration Characteristics for the 1784-PCMK (DH+)

If you want to:

Press this key:

Assign a unique communication device name (1-8 characters). This

field must be defined for the software to accept the configuration.

You cannot modify this field. The communication device name that

you assign appears at the top of the screen when you use WHO.

Device Name

Assign a description for a communication device (1-50 characters).

You must define this field for the software to accept

the configuration.

Enter Device Description

Select the 1784-PCMK (DH+) option.

Select Interface Hardware

Assign a timeout for processor reply. Available choices are: 15, 20,

25, 30, 35, 40, 45, 50, 55 and 60 seconds. The default is

20 seconds.

Online Wait for Reply

Choose the 1784-PCMK communications board address. You can

choose from the following:
·A300H (A3)

· CB00H (CB)

·A700H (A7)

· CF00H (CF)

·AB00H (AB)

· D300H (D3)

·AF00H (AF)

· D700H (D7)

·B300H (B3)

· DB00H (DB)

·B700H (B7)

· DF00H (DF)

·BB00H (BB)

· E300H (E3)

·BF00H (BF)

· E700H (E7)

·C300H (C3)

· EB00H (EB)

·C700H (C7)

PCMK Communications

Board Addr

Enter a name for a programming terminal (1-8 characters). This

name appears next to the station number and device on the WHO

active screen.

Term Name

(Continued)
