Preface
ControlGuardian User’s Guide
3-34
Configuring a Sutherland Schultz 5136-SD/SD2 to DH485
For information on the configuration characteristics for a Sutherland Schultz
5136-SD/SD2 to DH485, see Table 3.AB.
Table 3.AB
Configuration Characteristics for Sutherland Schultz 5136-SD/SD2 to
DH485
If you want to: Press this key:
Assign a unique communication device name (1-8 characters). This
field must be defined for the software to accept the configuration.
You cannot modify this field. The communication device name that
you assign appears at the top of the screen when you use WHO.
F1
Device Name
Assign a description for a communication device (1-50 characters).
You must define this field for the software to accept
the configuration.
F2
Enter Device Description
Select the Sutherland Schultz 5136-SD/SD2 to DH485 option.
F3
Select Interface Hardware
Assign a timeout for processor reply. Available choices are: 15, 20,
25, 30, 35, 40, 45, 50, 55 and 60 seconds. The default is
20 seconds.
F4
Online Wait for Reply
Enter SD bit address. The default is D800.
F5
SD Communications Board
Address
Enter SD interrupt number. The default is 5.
F6
SD Communications Board
IRQ
Enter SD Port Address number. The default is 0250.
F7
SD Communications Board
Port
Enter the 1785-KA5 DH+ address (0-77 octal).
F8
1785-KA5 Address
Enter a destination link DH+ address (decimal).
F9
Destination Link
Enter the source station address (0-377 octal).
F1 Ctrl
Computer Station Address
