Configuring Communications

3-11

For information on the configuration characteristics for 1784-KT/KT2 (DH+), see

Table 3.G.

Table 3.G

Configuration Characteristics for the 1784-KT/KT2 (DH+)

If you want to:

Press this key:

Assign a unique communication device name (1-8 characters). This

field must be defined for the software to accept the configuration.

You cannot modify this field. The communication device name that

you assign appears at the top of the screen when you use WHO.

Device Name

Assign a description for a communication device (1-50 characters).

You must define this field for the software to accept

the configuration.

Enter Device Description

Select the 1784-KT/KT2 (DH+) option.

Select Interface Hardware

Assign a timeout for processor reply. Available choices are: 15, 20,

25, 30, 35, 40, 45, 50, 55 and 60 seconds. The default is

20 seconds.

Online Wait for Reply

Choose the 1784-KT/KT2 communications board address. You can

choose from the following:
·C000H (000011)

· D000H (001011)

·C400H (100011)

· D400H (101011)

·C800H (010011)

· D800H (011011)

·CC00H (110011)

· DC00H (111011)

KT Communications

Board Addr

Enter a name for a programming terminal (1-8 characters). This

name appears next to the station number and device on the WHO

active screen.

Term Name

Define the following:
·Network mode (choose between: local, remote, and DH+ routing)
·Local node address (octal)
·Remote address (octal)
·Destination link ID (decimal) for DH+ routing
·Bridge address (octal) for DH+ routing

Network Mode

Enter the source station address (0-77 octal).

Ctrl

Computer Station Address

The actual device drivers for the 1784-KT or 1784-KT2 communications cards are

separate so you can specify both in one batch file.
