Configuring a Sutherland Schultz 5136-SD Board (DH+)
For information on the configuration characteristics for a Sutherland Schultz
5136-SD Board (DH+), see Table 3.J.
Table 3.J
Configuration Characteristics for the Sutherland Schultz 5136-SD (DH+)
If you want to: Press this key:
Assign a unique communication device name (1-8 characters). This
field must be defined for the software to accept the configuration.
You cannot modify this field. The communication device name that
you assign appears at the top of the screen when you use WHO.
F1
Device Name
Assign a description for a communication device (1-50 characters).
You must define this field for the software to accept
the configuration.
F2
Enter Device Description
Select the S&S 5136-SD (DH+) option.
F3
Select Interface Hardware
Assign a timeout for processor reply. Available choices are: 15, 20,
25, 30, 35, 40, 45, 50, 55 and 60 seconds. The default is
20 seconds.
F4
Online Wait for Reply
Enter SD bit address. The default is D800.
F5
SD Communications Board Address
Enter SD interrupt number. The default is 5.
F6
SD Communications Board IRQ
Enter SD Port Address number. The default is 0250.
F7
SD Communications Board Port
Enter the source station address (0-77 octal).
F1 Ctrl
Computer Station Address
