Page 143

Generating and Printing Reports

10-9

Use Table 10.D to help choose which ladder print mode you want to use:

Table 10.D

Choosing which Ladder Print Mode to Use

If you want to:

Choose this mode:

Print the ladder report using ControlGuardian’s standard font.

Longer rungs may wrap on multiple lines of the report.

normal

Print the ladder report using a smaller font so longer rungs don’t

wrap on multiple lines.

compressed

Alternate between normal and compressed font sizes as needed,

depending on the width of each rung and its text description.

enhanced

Alternate between normal and compressed modes as needed,

depending on the width of each rung and its text description.

normal/compressed

Print the ladder report in compressed mode, but without any page

breaks. This option provides a continuous report listing.

raw compressed

Print the ladder report in normal mode, but without any page

breaks. This option provides a continuous report listing.

raw normal

Table 10.E

Ladder Parms 2 Function Key Descriptions

If you want to:

Press this key:

Enable output cross-reference on the ladder printout and determine their

placement. Toggle through none, below, side, and side/below. The default

is none.

The side/below option prints as many cross-references as possible to the right

of the rung and then continues with additional cross-references below.

Output Xref

Print a rung number reference below input instructions indicating the next

occurrence of that address as an output. Toggle between yes and no. The

default is yes.

Input Xref

Determine cross-reference print mode. Toggle between Normal and

Compressed. Normal mode includes the specific instruction types for each

reference. Compressed mode is abbreviated. The default is normal.

Ladder Xref Print Mode

Choose to ignore or acknowledge a disable flag in the data base. Toggle

between yes and no. If yes, this option ignores the disable flag without

changing the data base. The default is no.

Ignore Xref Disable Flg

Choose to have the address always appear along with the

cross-reference data. Toggle between yes and no. The default is no.

Force Addr on Side Xref

Specify the maximum number of horizontal characters to allow for

cross-reference data to the right of the rung diagram. The default is 32.

Side Xref Column Width

Enable or disable the printing of the right power rail. You can disable the

printing of the right power rail as long as the side cross-reference print

is disabled. Toggle between yes and no. The default is yes.

Print Right Power Rail

Note:

Cross-reference parameters are only available with A.I. series programs.

Application tip
