Preface ControlGuardian User’s Guide
4-8
Inserting SLC 500 Files into the Master Library
ControlGuardian supports the .ACH format of SLC 500 files. ControlGuardian uses
SLC 500 to upload and download files. To insert SLC 500 files into the master
library, do the following:
Use function keys to select
SLC 500.
Identifies the
master directory
Press
Ins
to display the
Use the keys to highlight the file
that you want to insert into the master
library (or change directories and then
choose a file to insert).
production directory.
Press
The system displays the master library
with the inserted file highlighted.
Main Menu
F1
Master Program
Library
Enter
¬
-
®
¯
6 2 0
2 0
SLC 500 MASTER
PRACTICE.ACH
Select MASTER SLC 500 Proj RUNBATCH.ACH
*.ACH
128 02-23-96 04:00:25p
128 02-27-96 10:11:25p
