Configuring Communications
3-23
Configuring a Serial Port to A-B 1747-PIC
For information on the configuration characteristics for Serial Port to A-B
1747-PIC, see Table 3.Q.
Table 3.Q
Configuration Characteristics for Serial Port to A-B 1747-PIC
If you want to: Press this key:
Assign a unique communication device name (1-8 characters). This
field must be defined for the software to accept the configuration.
You cannot modify this field. The communication device name that
you assign appears at the top of the screen when you use WHO.
F1
Device Name
Assign a description for a communication device (1-50 characters).
You must define this field for the software to accept
the configuration.
F2
Enter Device Description
Select the Serial Port to A-B 1747-PIC option.
F3
Select Interface Hardware
Assign a timeout for processor reply. Available choices are: 15, 20,
25, 30, 35, 40, 45, 50, 55 and 60 seconds. The default is
20 seconds.
F4
Online Wait for Reply
Assign a communication port. Toggle through COM1, COM2, and
user specified. If you choose the user-specified port, you must
enter the serial port I/O address and the interrupt (IRQ). For more
information about specifying a COM port, see page 3-8.
F5
Communications Port
Define a communication rate to send information. Toggle through
300, 600, 1200, 2400, 4800, 9600 and 19200 baud rates. The
default is 19200 baud.
F6
Baud Rate
