Preface

ControlGuardian User’s Guide

3-26

Configuring an A-B 1784-KR

For information on the configuration characteristics for A-B 1784-KR, see

Table 3.T.

Table 3.T

Configuration Characteristics for A-B 1784-KR

If you want to:

Press this key:

Assign a unique communication device name (1-8 characters). This

field must be defined for the software to accept the configuration.

You cannot modify this field. The communication device name that

you assign appears at the top of the screen when you use WHO.

Device Name

Assign a description for a communication device (1-50 characters).

You must define this field for the software to accept

the configuration.

Enter Device Description

Select the A-B 1784-KR option.

Select Interface Hardware

Assign a timeout for processor reply. Available choices are: 15, 20,

25, 30, 35, 40, 45, 50, 55 and 60 seconds. The default is

20 seconds.

Online Wait for Reply

Choose the 1784-KL communications board address. You can

choose from the following:
·C000H

· E000H (000111)

·C800H

· E800H (010111)

·D000H
·D800H

KR Memory Address

Define a communication rate to send information. Toggle through

300, 600, 1200, 2400, 4800, 9600 and 19200 baud rates. The

default is 19200 baud.

Baud Rate

Choose the KR I/O board address. you can choose from 2A8, 2B8,

2E8, 300, 320, and 360. The default is 300.

KR I/O Board Address

Choose the KR interrupt number. You can choose from 2, 3, 4,

and 5. The default is 5.

KR Interrupt Number

Enter the source station address (decimal).

Ctrl

Computer Station Address
