Preface
ControlGuardian User’s Guide
3-32
Configuring an A-B 1784-KTX/KTXD to DH485
For information on the configuration characteristics for 1784-KTX/KTXD to
DH485, see Table 3.Z.
Table 3.Z
Configuration Characteristics for A-B 1784-KTX/KTXD to DH485
If you want to: Press this key:
Assign a unique communication device name (1-8 characters). This
field must be defined for the software to accept the configuration.
You cannot modify this field. The communication device name that
you assign appears at the top of the screen when you use WHO.
F1
Device Name
Assign a description for a communication device (1-50 characters).
You must define this field for the software to accept
the configuration.
F2
Enter Device Description
Select the A-B 1784-KTX/KTXD to DH485 option.
F3
Select Interface Hardware
Assign a timeout for processor reply. Available choices are: 15, 20,
25, 30, 35, 40, 45, 50, 55 and 60 seconds. The default is
20 seconds.
F4
Online Wait for Reply
The 1784-KTX communication card can use any 4KB block of
memory on any 4K boundary between A000 and EF00
(hexadecimal).
F5
KTX Communications
Board Addr
Enter a programming terminal name (1- 8 characters).
F6
Terminal Name
Enter the 1785-KA5 DH+ address (0-77 octal).
F8
1785-KA5 Address
Enter a destination link DH+ address (decimal).
F9
Destination Link
Enter the source station address (0-377 octal).
F1 Ctrl
Computer Station Address
