Rockwell Automation 2711E-ND1 PanelBuilder 1400E Reference Manual User Manual
Page 21

10
ASCII Inputs
Publication 2711E-820 – January 1998
Field
Meaning
Control (con’t)
If the terminal does not receive acknowledgment (transition
from 0 to non-0) within the Enter Key Handshake Time (as
specified in the Timing Parameters tab of the Terminal Setup
dialog box), it displays an error message in the Fault Window
and resets the Enter Key Control. If the Enter Key Handshake
is unassigned, the Enter Key Control remains set for the
duration of the Push Button Hold Time or for as long as the
button is pressed, whichever is longer.
Because this control uses only two values, a digital tag is
recommended.
Important: If the Enter Key Control is assigned, all keypad
and touch screen input is disabled when the Enter Key is
pressed, until the Enter Key Control is reset to 0.
You can adjust the size of the scratchpad and format the ASCII Input
object’s foreground color, background color, font style, and border
style. For details on formatting objects see “Changing Object
Appearance,” in Chapter 9, Creating Objects, in the PanelBuilder
1400e Configuration Software for Windows User Manual.
Note: If you use the Extra Large Font the application will be
compatible with PanelView Version 2 or later. It will not be
compatible with earlier versions.
"
