Appendix
A
Publication 2711E-820 – January 1998
ISA Symbols
This appendix lists all the ISA symbols provided with PanelBuilder
1400e. If you followed the default installation, they are in the
\IMAGES\ISA directory.
You can use any monochrome image as a Symbol object, including
these bitmaps of standard ISA symbols. You can also use these
bitmaps as Graphic Images. Each bitmap is available in two sizes. The
file name containing the ‘l’—for example, ‘agitatrl.bmp’—indicates
the bitmap is the large size.
Symbol Name File Names ISA Symbol Icon
Agitator agitatr.bmp
Blower blower.bmp
Compressor comprsr.bmp
Conveyor conveyr.bmp
Cyclone Separator cyclone.bmp
Distillation Tower distowr.bmp
Exchanger exchngr.bmp
Liquid Filter ftrliqd.bmp
Vacuum Filter ftrvacm.bmp
Furnace furnace.bmp
Inline Mixer inlmixr.bmp
Symbol Icons
