106 Screen Selectors
Publication 2711E-820 – January 1998
This button allows the operator to choose the next screen to be
displayed by entering the screen number on the terminal’s numeric
keypad.
At runtime, when the button is pressed, a scratchpad appears on the
top 60 pixels of the screen. The operator enters the screen number in
the scratchpad using the terminal’s numeric keypad.
The keys on the numeric keypad function as follows:
This key Does this
Enter Removes the scratchpad and current screen and displays
the screen with the screen number that was in the
scratchpad.
Number keys Enter numbers in the scratchpad.
Delete Deletes the last digit entered in the scratchpad.
Cancel Removes the scratchpad and cancels the screen change.
Note: Operator input is disabled for a short time when the
scratchpad is first displayed. This may result in a delay before the
first digit can be entered.
Configuring the Screen Keypad Enable Button
Configure the Screen Keypad Enable Button according to this table:
Field Meaning
Name Assign a name, up to 15 characters, to document the object for
printed reports. This increases the application’s size by 1 byte
per character.
Function Key Specify which function key the operator must press to activate
this button.
You can adjust the size of the Screen Keypad Enable Button and
format its foreground color, background color, fill style, and blink
attributes. For details on formatting objects see “Changing Object
Appearance,” in Chapter 9, Creating Objects, in the PanelBuilder
1400e Configuration Software for Windows User Manual.
Screen Keypad Enable
Button
(Keypad Terminals Only)
"
