Equipment parts – Rockwell Automation 2711E-ND1 PanelBuilder 1400E Reference Manual User Manual
Page 172
Arrows and Parts
C–2
Publication 2711E-820 – January 1998
File Name
Arrow Shape
File Name
Arrow Shape
You can use these bitmaps of equipment parts as graphic images.
Since they are not monochrome you cannot use them as Symbols.
The images are presented alphanumerically by file name in the tables
that follow, to match the order in which they are listed in the Select
Image dialog box.
Image Type
File Name
Equipment Part Graphic Image
File Name
Equipment Part Graphic Image
Buttons
Equipment Parts
