1785-UM022C-EN-P - February 2008
A-2
Hardware Addressing 2-slot
• Any mix of 8-pt modules
• 16-pt modules must be I/O pairs
• No 32-pt modules
1-slot
• Any mix of 8- or 16-pt modules
• 32-pt modules must be I/O pairs
1/2-slot—Any mix of 8-,16-, or 32-pt modules
Communication • Serial
• DH+
• DH using 1785-KA
• Remote I/O
• ControlNet
Wire Category 2
4
• Relay Cartridge
Wire Category 1
4
Location 1771-A1B, -A2B, A3B, -A3B1, -A4B chassis; left-most slot
Weight PLC-5/20C15: 3 lbs, 3 oz (1.45 kg)
PLC-5/40C15: 3 lbs, 2 oz (1.42 kg)
PLC-5/46C15: 3 lbs, 2 oz (1.42 kg)
PLC-5/80C15: 3 lbs, 2 oz (1.42 kg)
Keying • Between 40 and 42
• Between 54 and 56
Certifications
(when product is marked)
UL UL Listed Industrial Control Equipment
CSA CSA Certified Process Control Equipment
CSA CSA Certified Process Control Equipment for Class I, Division 2 Group
A,B,C,D Hazardous Locations
CE
5
European Union 89/336/EEC EMC Directive, compliant with:
EN 50081-2; Industrial Emissions
EN 50082-2; Industrial Immunity
European Union 73/23/EEC LVD Directive, compliant with:
EN 61131-2; Programmable Controllers
C-Tick
5
Australian Radiocommunications Act, compliant with:
AS/NZS 2064; Industrial Emissions
1 The clock/calendar will update appropriately each year.
2 The 1785-CHBM cannot be used with the 1785-5/60C processor.
3 The 1785-ME16 cannot be used with ControlNet PLC-5 processors.
4 For more information, refer to publication 1770-4.1, Industrial Automation Wiring and Grounding Guidelines.
5
See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates, and other certification details.
