Monitoring and troubleshooting, Your controlnet system, Chapter – Rockwell Automation 1785-Lx0C15 ControlNet PLC-5 Programmable Controllers User Manual User Manual
Page 91
1785-UM022C-EN-P - February 2008
Chapter
5
Monitoring and Troubleshooting
Your ControlNet System
Using This Chapter
Using the General Status
Indicators
The general status indicators inform you of the general operational
state of the processor.
Topic
Page
Using the general status indicators
5-1
Using the ControlNet status indicators
5-3
Using the Data Highway Plus and Remote I/O Status Indicators
5-5
Monitoring the ControlNet configuration and status
5-5
Using the DH+/RIO Status Indicators
5-6
Indicator
Color
Description
Probable Cause
Recommended Action
BATT
Red
Battery low
Battery low
Replace battery within 10 days
Off
Battery is good
Normal operation
No action required
BATT
PROC
FORCE
COMM
