1785-UM022C-EN-P - February 2008
Installing Your ControlNet PLC-5 Processor 1-5
Before You Install the
Programmable Controller Before installing your ControlNet PLC-5 processor:
1. Check your processor package, and make sure that you have the
following:
If any items are missing or incorrect, contact your local Rockwell
Automation sales office or distributor.
2. Install and connect a chassis and power supply.
Use the following table to find more information about completing
these tasks:
ControlNet PLC-5
®
Programmable Controller,
1785-L20C15, -L40C15, -L46C15, or -L80C15
Contents of Tray 1 Lithium Battery, 1770-XYC
1 DIN connector cover
4 Terminating resistors—150 Ω 1
2 or 4 2 Terminating resistors—82 Ω 3
2 or 4 2 3-pin connectors
2 Keys
1 Battery cover with screw
1 1784-CP7 cable adapter for 1784-CP,
-CP5 cables
ControlNet PLC-5 Programmable Controllers Quick
Start, publication number 1785-10.6
1 Identified by four colored bands: brown, green, brown, and gold
2 Two with a PLC-5/20C processor, four with PLC-5/40C, -5/46C and -5/80C
processors
3 Identified by four colored bands: gray, red, black, and gold
Processor
Documentation
Chassis Type Chassis Document Power Supply Power Supply Document
1771-A1B, -A2B, -A3B, - A3B1, -A4B 1771-2.210 1771-P1 1771-2.6
1771-P2 1771-2.7
1771-P3 1771-2.111
1771-P4 1771-2.111
1771-P4R 1771-5.3
1771-P4S 1771-2.13
1771-P5 1771-2.111
1771-P6R 1771-5.3
1771-P6S 1771-5.11
1771-P7 1771-5.56
