1785-UM022C-EN-P - February 2008
ControlNet I/O Map-Entry Status Words and Error Codes D-5
38 0x0026 INVALID DESTINATION
ADDRESS SIZE The map table is corrupted. Reenter the I/O map entry that is
failing.
The target node of the MSG
instruction is not a processor or the
target node of the CIO instruction is
not the correct I/O adapter. Edit the ladder program so that the
correct target node is used.
Replace the target node with the
correct type of node.
256 0x0100 CONNECTION IN USE The connection at the target node is
already in use. No action is required. The
connection can be re-established
after the target node times out the
old connection.
262 0x0106 CONNECTION USED BY OTHER
NODE The originating node attempted to
use a connection that is already
being used by another node. Delete or inhibit any other node’s
connection so that the preferred
node can establish the connection.
A non-discrete connection is setup
to a discrete module. Replace the target module with the
correct non-discrete module.
Correct the I/O map table.
263 0x0107 CONNECTION NOT FOUND The connection at the target node
does not exist. Make sure I/O map entries exist in
the I/O map tables of both the
originating and target nodes.
265 0x0109 INVALID CONNECTION SIZE The originating node requested a
connection size that the target node
cannot accommodate. Correct the connection size in the
map table. If it is a listen-only
connection, make sure that the
connection size is not larger that the
size of the controlling connection.
Set the addressing mode switches
of the 1771 rack dip correctly.
Use a rack with the correct number
of slots.
273 0x0111 INVALID RPI The target node cannot produce the
data at or faster than the requested
packet interval (RPI) entered in the
map table. Increase the requested packet
interval (RPI) entered in the map
table.
275 0x0113 OUT OF CONNECTIONS The maximum number of
connections to/from this node has
been exceeded. Reduce the number of I/O
connections, MSG instructions, or
CIO instructions to/from this node.
276 0x0114 PRODUCT CODE MISMATCH The target node/module does not
match the node/module entered in
the map table. Replace the target node/module
with the correct node/module.
277 0x0115 PRODUCT TYPE MISMATCH Correct the I/O map table.
278 0x0116 REVISION MISMATCH The series/revision of the target
node/module does not match the
series/revision entered in the map
table. Replace the target node/module
with the correct node/module.
Correct the I/O map table.
Decimal
Code Hex. Code Error Message Explanation/Possible Cause(s) Possible Corrective Action(s)
