1785-UM022C-EN-P - February 2008

Processor Status File

B-5

10

Run-time data table check failed

Recoverable:
the fault routine can instruct
the processor to clear the
fault and then resume
scanning the program.

A fault routine executes
when any of these faults
occur.

11

Bad user program checksum

12

Bad integer operand type, restore new processor memory file

13

Bad mixed mode operation type, restore new processor memory file

14

Not enough operands for instruction, restore new processor memory file

15

Too many operands for instructions, restore new processor memory file

16

Corrupted instruction, probably due to restoring an incompatible processor memory file (bad opcode)

17

Can’t find expression end; restore new processor memory file

18

Missing end of edit zone; restore new processor memory file

19

Download aborted

20

You entered too large an element number in an indirect address

21

You entered a negative element number in an indirect address

22

You tried to access a non-existent program file

23

You used a negative file number, you used a file number greater than the number of existing files, or you
tried to indirectly address files 0, 1, or 2

24

You tried to indirectly address a file of the wrong type

Recoverable

30

You tried to jump to one too many nested subroutine files

Non-recoverable:
the fault routine will be
executed but cannot clear
major fault bit 2.

31

You did not enter enough subroutine parameters

32

You jumped to an invalid (non-ladder) file

33

You entered a CAR routine file that is not 68000 code

34

You entered a negative preset or accumulated value in a timer instruction

Recoverable

35

You entered a negative time variable in a PID instruction

36

You entered an out-of-range setpoint in a PID instruction

37

You addressed an invalid module in a block-transfer, immediate input, or immediate output instruction

38

You entered a RET instruction from a non-subroutine file

Non-recoverable
the fault routine will be
executed but cannot clear
major fault bit 2.

39

FOR instruction with missing NXT

40

The control file is too small for the PID, BTR, BTW, or MSG instruction

Recoverable

This
fault
code:


Indicates this fault:


And the fault is:
