Rockwell Automation 1785-Lx0C15 ControlNet PLC-5 Programmable Controllers User Manual User Manual
Page 30
1785-UM022C-EN-P - February 2008
1-18
Installing Your ControlNet PLC-5 Processor
For detailed information about planning and installing your
ControlNet system, see the following publications:
To view or order these publications online, visit:
http://literature.rockwellautomation.com
Publication
Publication Number
ControlNet Cable System Component List
AG-2.2
ControlNet Cable System Planning and Installation Manual
1786-6.2.1
ControlNet Network Access Cable Installation Instructions
1786-2.6
ControlNet Fiber Planning and Installation Guide
CNET-IN001A-EN-P
System Design for Control of Electrical Noise
GMC-RM001A-EN-P
Industrial Automation Wiring and Grounding Guidelines
1770-4.1
Terminating Your ControlNet Coaxial Cables CD-ROM
CNET-DM001A-EN-C
