1785-UM022C-EN-P - February 2008
B-6 Processor Status File
41 NXT instruction with missing FOR Non-recoverable
the fault routine will be
executed but cannot clear
major fault bit 2.
42 You tried to jump to a non-existent label
43 File is not an SFC
44 Error using SFR. This error occurs if:
• you tried to reset into a simultaneous path
• you specified a step reference number that is not found or is not tied to a step (it is a transition)
• the previous SFR to a different step is not complete
45 Invalid channel number entered Recoverable
46 Length operand of IDI or IDO instruction is greater than the maximum allowed
47 SFC action overlap. An action was still active when the step became re-activated Non-recoverable
48-69 Reserved Recoverable
70 The processor detected duplicate labels
71 The processor tried to start an SFC subchart that is already running
72 The processor tried to stop an SFC subchart that isn’t running
73 The processor tried to start more than the allowed number of subcharts
74 SFC file error detected
75 The SFC has too many active functions
76 SFC step loops back to itself.
77 The SFC references a step, transition, subchart, or SC file that is missing, empty or too small
78 The processor cannot continue to run the SFC after power loss
79 You tried to download an SFC to a processor that cannot run SFCs
80 You have an I/O configuration error Recoverable
81 You illegally set an I/O chassis backplane switch by setting both switch 4 and 5 on
82 Illegal cartridge type for selected operation. This error also occurs if the processor doesn’t have a
memory module, but the backplane switches are set for a memory module. Make sure the backplane
switches are correct (set switch 6 ON and switch 7 OFF if the processor doesn’t have a memory module).
This
fault
code:
Indicates this fault:
And the fault is:
