2-34 Planning to Use Your ControlNet PLC-5 Processor
Converting from a Non-ControlNet
Remote I/O System to a ControlNet
I/O System When you download archived files to a ControlNet PLC-5 processor,
the programming software ignores Channel 2 configuration
information from anything other than a ControlNet-processor
program because Channel 2 is reserved for ControlNet
communication on the ControlNet processors. The software sets
Channel 2 to the default ControlNet configuration.
Program files
1
for this process:
Archived from a:
On channel:
Can be run on a
ControlNet
PLC-5 channel:
If they fit and are:
Messaging and I/O • PLC-5/11
• PLC-5/20
• PLC-5/20C15
• PLC-5/20E
• PLC-5/30
• PLC-5/40
• PLC-5/40C15
• PLC-5/46C15
• PLC-5/40E • PLC-5/40L
• PLC-5/60
• PLC-5/60L
• PLC-5/80
• PLC-5/80C15
• PLC-5/80E 0 0 downloaded unchanged
1A 1A
• PLC-5/20
• PLC-5/20C15
• PLC-5/20E
• PLC-5/30
• PLC-5/40
• PLC-5/40C15
• PLC-5/46C15
• PLC-5/40E • PLC-5/40L
• PLC-5/60
• PLC-5/60L
• PLC-5/80
• PLC-5/80C15
• PLC-5/80E 1B 1B
• PLC-5/20C15
• PLC-5/40C15 • PLC-5/46C15
• PLC-5/80C15 2 2
