1785-UM022C-EN-P - February 2008
ControlNet I/O Map-Entry Status Words and Error Codes D-3
The following table explains the second and third status words in the
ControlNet I/O status file.
ControlNet I/O Connection
Type Bit 9 of First Word
of I/O Status File Entry
(Connection Error) Second Word
of I/O Status File Entry Third Word
of I/O Status File Entry
All Set 0 Error code (see the “Error Messages” section)
Receive Data Clear 0 0 = peer processor is in PROGRAM mode
1 = peer processor is in RUN mode
Send Data Clear 0 Number of peer listeners
1747 Discrete Clear If bit x is clear, then the module in slot x is OK.
If bit x is set, then the module in slot x is missing, bad, or is the wrong type.
1747 Analog Clear 0 0
1771 Discrete Clear 0 0
1771 Analog Read Clear 0 Error code from read
1771 Analog Write Clear Error code from write 0
1771 Analog Read/Write Clear Error code from write Error code from read
1794 Discrete Clear 0 If bit x is clear, then the module in slot x is OK.
If bit x is set, then the module in slot x is missing, bad,
or is the wrong type.
1794 Analog Read Clear 0 If bit x is clear, then the module in slot x is OK.
If bit x is set, then the module in slot x is missing, bad,
or is the wrong type.
1794 Analog Write Clear 0 0
1794 Analog Read/Write Clear 0 If bit x is clear, then the module in slot x is OK.
If bit x is set, then the module in slot x is missing, bad,
or is the wrong type.
