1785-UM022C-EN-P - February 2008
Planning to Use Your ControlNet PLC-5 Processor 2-31
Using the ControlNet
PLC-5 Processor in a
ControlNet I/O System
There can be multiple ControlNet PLC-5 processors updating I/O
adapters on a ControlNet network.
• any processor can own adapters on the network
• any processor is allowed to send CIO instructions to I/O modules
• additional processors can do scheduled transfers to any other
processor on the ControlNet network by using peer-to-peer
communications through the scan configuration list
The following table describes various ControlNet devices that you
can add to your network. For a complete listing, contact your local
Rockwell Automation sales office.
Catalog Number(s) Device(s) Function
1785-L20C15,
-L40C15, -L46C15,
-L80C15 ControlNet Programmable Controllers Communicate with other ControlNet nodes using scheduled or unscheduled
peer-to-peer communication.
1784-KTC15,
-KTCX15, -KTCS ControlNet ISA Communication Cards Allows other computer platforms to communicate with the ControlNet network.
1784-PCC ControlNet PCMCIA Communication Card Allows other computer platforms to communicate with the ControlNet network.
1770-KFC15,
-KFCD15 ControlNet Serial/Parallel Communication
Interface Connects a serial or parallel device to a ControlNet network.
1747-ACN15,
-ACNR15 1747 ControlNet SLC I/O Adapters Allows the ControlNet processor remote access to Allen-Bradley’s family of
SLC-designated I/O modules via a ControlNet network.
1771-ACN15,
-ACNR15 1771 ControlNet I/O Adapters Allows the ControlNet processor remote access to Allen-Bradley’s family of
1771-designated I/O modules via a ControlNet network.
1784-PCIC, -PCICS ControlNet PCI Communication Cards Allows other computer platforms to communicate with the ControlNet network.
1794-ACN15,
-ACNR15 1794 ControlNet FLEX I/O Adapters Allows the ControlNet processor remote access to Allen-Bradley’s family of
1794-designated I/O modules via a ControlNet network.
1797-ACN15 1797 ControlNet Ex I/O Adapter Allows the ControlNet processor remote access to Allen-Bradley’s family of
1797-designated I/O modules via a ControlNet network.
1788-CN2DN,
-CN2FF 1788 ControlNet Linking Devices Allows the ControlNet processor to link to DeviceNet or Foundation Fieldbus
networks.
1756-CNBR,
1756-CN2 ControlLogix ControlNet Bridge Allows the ControlNet processor remote access to Allen-Bradley’s family of
1756 controllers via a ControlNet network.
PV 550, 600, 900,
1000, 1400, 1000e
and 1400e Panel View ControlNet products with
ControlNet comm option Allows the ControlNet processor remote access to Allen-Bradley’s PanelView
ControlNet operator interfaces via a ControlNet network.
1203-CN1 Any scan port drive or device that
communicates thru 1203-CN1 Allows the ControlNet processor remote access to Allen-Bradley’s scan port
drives or devices that communicate through a 1203-CN1 via a ControlNet
network.
1336T AC Vector
Drive, 1395 Digital
DC Drive Drives with direct fiber ControlNet
connections Allows the ControlNet processor remote access to Allen-Bradley’s AC Vector
and Digital DC drives via a ControlNet network.
