52 Rockwell Automation Publication 57RF-UM001A-EN-P - September 2011
Chapter 6
iv. Enter the Key index number if different than 1.
v. If you are utilizing the 802.1x authentication method in a WEP
Open network, you will have to checkmark the Enable 802.1x
authentication
checkbox.
vi. Clear the Enable 802.1x authentication checkbox if you are not
utilizing the 802.1x authentication method.
6. Click OK to save the settings and exit. The Wireless Information dialog
window will reappear and the handheld computer will attempt to make a
connection to that network.
7. If the connection was successful, a blue halo will appear on the icon next to
the connected wireless network name, as shown below.
8. Click OK to exit the Wireless Configuration dialog box.
9. To verify that you have a successful network connection, launch Internet
Explorer and type in a known web address. That page should appear on
your display. For example:
IMPORTANT In addition, if you are using WPA as your authentication method, you may
need an additional 802.1x authentication configuration.
