Displays, Keypads, Indicators – Rockwell Automation 57RF RFID ICODE Handheld Interface User Manual User Manual
Page 10: Interface capabilities, Durability, Ingress protection
10
Rockwell Automation Publication 57RF-UM001A-EN-P - September 2011
Chapter 1
Displays
The RFID ICODE handheld interface features a supertwist nematic liquid
crystal 320 x 240 QVGA-TFT color sunlight readable display with touch screen
and LED backlight.
Keypads
Keypad configurations for the RFID ICODE handheld interface include the
45-key pad and 52-key with directional pad.
Indicators
The RFID ICODE handheld interface has five programmable LED indicators
that can provide a number of useful functions including the state of keypad
modifier keys. An additional LED indicates the current charge or low battery
status.
Interface Capabilities
The RFID ICODE handheld interface comes standard with one USB port and
one RS-232 serial port. The RFID ICODE handheld interface also includes Wi-
Fi and Bluetooth®.
Durability
The case is made of General Electric Xenoy®, one of the most durable chemical
resistant materials available today.
Ingress Protection
The RFID ICODE handheld interface is completely dust-tight and can
withstand exposure to jets of water and has an IP (Ingress Protection) rating of 65
as defined by IEC standard 529.
