13 Appendix
98
Interfaces
LCD display
Approvals/approval marks
Setup interface
- Baud rate
- PC interface 9600
with TTL/RS232 or USB/TTL converter
RS485 interface
- Protocol
- Baud rate
- Device address
- Minimum response time Modbus
9600, 19200, 38400
1 to 254
0 to 500 ms
Top line 4-digit 7-segment display, 4.5 mm high
Bottom line 5-digit 16-segment display, 4.0 mm high
Approval
mark Testing agency Certificate/
certification numbers
Inspection basis Valid for
c UL us Underwriters
Laboratories E201387 UL 61010-1
CAN/CSA-C22.2
No. 61010-1 915 MHz, 230 V,
basic type 902931/
10
IC Industry Canada 7472A-WTRANST01
7472A-WTRANST0102
RSS-210 Issue 7
RSS-210 Issue 8
RSS-GEN Issue 3
RSS-102 Issue 4
915 MHz, 230 V,
basic type 902931/
10
FCC Federal
Communications
Commission VT4-WTRANST01
VT4-WTRANST01-02
FCC Rule Part 15C
FCC Rule Part 15C
915 MHz, 230 V,
basic type 902931/
10
