background image

9

2 Identifying the device version

2.1

Nameplate

Position

The nameplate is affixed to the device.

Content

The nameplate contains important information, including:

Typ

Please check the type supplied against your order document. To identify the type, use Chapter
2.2 "Order details", page 10.

TN

The part no. clearly identifies an article in the catalog. It is used in communication between the
sales department and the customer.

F-Nr

The fabrication number is used by the manufacturer to identify the device.
The fabrication number indicates, among other things, the production date (year/week) and the
hardware version.

Production date
Example: F-Nr = 0139741001109490005
The relevant numbers are in positions 12, 13, 14, and 15.
The device was produced in the 49th calendar week of 2009.

Hardware version
Example: F-Nr = 0139741001109490005
If the eleventh digit (from the left) is 1 or above, the receiver is equipped with the following func-
tions:

Receipt of the input variables for RTD temperature probe, thermocouple, potentiometer,
and voltage

Customer-specific linearization

Scaling for the input variables for potentiometer or voltage

If the eleventh digit (from the left) is 0, it is a predecessor version that can only process the RTD
temperature probe "Pt1000" input variable.

Description

Designation
on the nameplate

Example

Device type

Typ

902931/10-8-10-23/000

Part no.

TN

00123456

Fabrication number

F-Nr

0139741001109490005

Voltage supply

AC 110 to 240 V +10/-15 %,
48 to 63 Hz
