8 Configuring the receiver
60
Relay outputs 1 to 2
The following table shows the parameters of relay output 1 that are to be set. Identical setting
options apply for relay output 2 (relay outputs are available with type T01.EC3).
Parameter Bottom
line
of dis-
play Top
line
of display Value range/selection 
Response K1.Mod no
nc Normally open contact
Normally closed contact
Control signal
(binary selector) K1.SEL 0 0 Not assigned
1 to 16 Wireless timeout,
channel 1 to 16
17 to 32 Analog alarm 1,
channel 1 to 16
33 to 48 Analog alarm 2,
channel 1 to 16
49 to 64 Low battery,
channel 1 to 16
65 to 66 Relay status 1 to 2
67 Collective alarm
68 Collective alarm
Wireless timeout,
channel 1 to 16
69 Collective alarm
Analog alarms 1,
channel 1 to 16
70 Collective alarm
Analog alarms 2,
channel 1 to 16
71 Collective alarm
Low battery,
channel 1 to 16
72 Collective alarm
Analog alarms 1/2,
channel 1 to 16
73 to 76 Modbus
remote control values,
binary 1 to 4
77 Fixed value ON
78 Fixed value OFF
